Radial Trim-Two Stereo Direct Box with Level Control

Description

The Trim-Two allows you to connect any playback device and interface it with balanced pro audio equipment without signal loss or hum and buzz from ground loops. It features two transformers which isolate and balance the audio output from your source device, eliminating noise and allowing you to use long cable runs without signal degradation. A handy mono sum switch makes it easy to reduce the output channel count or send the same signal to two destinations at once, and an accessible level control gives you the ability to adjust levels in an instant. Multiple input connector types make it easy to hook up any consumer line level playback source, from laptops & smartphones to DJ equipment. The completely passive design means that you never have to worry about powering the Trim-Two, making it truly plug & play. =+= Technical Specification
Audio circuit type
Passive, transformer based
Transformer
Custom
Number of channels
Dual channel (stereo)
Frequency response
20Hz to 20KHz
Dynamic range
>100dB
Total harmonic distortion
0.01%
Phase Deviation
<10° Input Impedance 10K Ω, unbalanced Output Impedance 2.8K Ω, balanced Maximum Input +20dB @ 20Hz Input pad, Mono Sum, Ground lift Input Connectors 1/4" RCA and 3.5mm input Output Connectors XLR-M output Extras Copper foil shield Construction 14 gauge steel chassis & outer shell Size (L x W x D) 3.3" x 5.0" x 2" (84 x 127 x 48mm) Weight 1.55 lbs (0.70 kg) Shipping size (L x W x D) 4" x 3" x 6.5" (102 x 76 x 165mm) Shipping weight 1.92 lbs (0.87 kg) Power Passive, no power required Conditions For use in dry locations only between 5°C and 40°C
